This System Includes

Outdoor Condenser Unit Qty: 1
Indoor Ceiling Cassette 24000 BTU Qty: 2, 12000 BTU Qty:1
Remote Control: 3
Installation Lineset Requried But Not Included

Features

AHRI certified with trusted quality
World Class DC Inverter Compressor
21 SEER Efficiency and variable speed DC inverter Technology
R410A refrigerant pre-charged
Remote controller for each indoor unit
Low Ambient Working Temp cooling 0F and -4F for Heating
Digital LCD display, Turbo mode, 3 fan speeds
Auto level swing louver, Wide angle air distribution, Auto Restart,
Dry coil mode for protection
Super Quiet with low noise level
Auto Restart for sudden power cut and return
Cleanable air filter
Auto Start with Power failure recovery
Self-diagnosis and Auto-Protection Function

40A Circuit Breaker required

BTUs Guide:
12000 BTU Covers approx 500-550 SQFt;

Dimension:

12000 BTU Cassette: 22.4" x 22.4" x 9.1"

24000 BTU Cassette: 33.1" x 33.1" x 9.4"

Please have your area inspected by HVAC technician and load calculation to be performed to determine if this system will be suitable to you, interior factor such as windows, ceiling height and insulation will affect cooling and heating result.

Warranty;
YMGI offer 7 years on compressor and 2 year on other parts
Please Note: Mini Split Systems must be installed by a licensed contractor to qualify for warranty.
We are able to customize indoor and outdoor unit. If you require a different size for indoor or outdoor unit please contact our customer support

Brand Name	YMGI
Model Info	1a0360ba-3fb3-45ec-873f-abbfcd2be188
Item model number	1a0360ba-3fb3-45ec-873f-abbfcd2be188
Efficiency	21.0
Capacity	5 Tons
Noise	41 Decibels
Installation Type	Split System
Form Factor	Cassette
Special Features	Heating And Cooling Function
Color	White
Voltage	2.4E+2 Volts (AC)
Wattage	211011.48 watts
Floor Area	450 Square Feet

Ductless Mini Split air Conditioner Heat Pump 60000 BTU 5 Ton 3 Zone 24000+24000+12000 Ceiling Cassette System with 25 Ft Line Set for Home, Residential, Commercial Home Business…
